| Manufacturer | Swarovski | Swarovski | Swarovski | Carl Zeiss | Leica |
|---|---|---|---|---|---|
| Model | NL Pure 10x52 | EL 10x50 Swarovision | SLC New 10x50 WB | Victory HT 10x54 | Ultravid HD-Plus 10x50 |
| Lens diameter [mm] | 52 | 50 | 50 | 54 | 50 |
| Magnification [x] | 10 | 10 | 10 | 10 | 10 |
| Angular field of view [deg] | 7.4 | 6.6 | 6.4 | 6.3 | 6.7 |
| Linear field of view [m/m] | 130/1000 | 115/1000 | 112/1000 | 110/1000 | 117/1000 |
| Exit pupil [mm] | 5.2 | 5 | 5 | 5.4 | 5 |
| Eye relief [mm] | 17 | 20 | 17 | 16 | 15 |
| Min. focusing dist. [m] | 3.3 | 2.8 | 5 | 3.5 | 3.3 |
| Twilight factor | 22.8 | 22.36 | 22.36 | 23.24 | 22.36 |
| Brightness | 27.04 | 25 | 25 | 29.16 | 25 |
| Prisms | BaK-4/roof | BaK-4/roof | BaK-4/roof | BaK-4/roof | BaK-4/roof |
| Dimensions [mm] | 174 x 131 x 77 mm | 174x134x67 | 126x196x69 | 193x142 | 178x125x70 |
| Weight [g] | 1020 | 998 | 1160 | 1050 | 1000 |
| Waterproof | Yes | Yes | Yes | Yes | Yes |
| Nitogen filling | Yes | Yes | Yes | Yes | Yes |
| Argon filling | No | No | No | No | No |
| Image stabilization | No | No | No | No | No |
| Tripod exit | Yes | Yes | Yes | No | No |
| Focusing | central | central | central | central | central |
| Guarantee [years] | 10 | 10 | 30 | 10 | 10 |
| Accesories | Carrying strap, Eyepiece cover, Objective lens cover filler piece, Strap loop connector, Functional side bag, cleaning cloth, soap, brush | Snap shot adapter, field bag, eyepiece cover, objective lens cover and lift carrying strap | Case, carrying strap, objective lens covers, eyepiece cover. | Neck strap, lens covers, case, cleaning cloth. | contoured neoprene carrying strap, front lens caps, eyepiece caps, cordura case |
| Price | 16000 | 10990 | 6700 | 0 | 0 |
| Additional information | Announced: June 2024 Waterproof up to 4 m Functional temperature: -25 °C to +55 °C Transmission 91%. | Announced: January 2011 Manufactured in 2011-2015 Light transmission: 90% Magnesium housing Waterproof up to 4 m Funcional temperature range from -25°C to +55°C Schmidt-Pechan prisms 6-element objective Fluoride-containing HD lenses Field flattener lenses SWAROBRIGHT, SWARODUR, and SWAROTOP coatings SWAROCLEAN non-stick coating | Manufactured in 2004-2013 3-element objective Schmidt-Pechan prisms SWAROTOP and SWARODUR coatings SWAROBRIGHT and P-coatings Waterproof up to 4 m Functional temperature from -25 C to +55 C. | Announced: March 2014. Abbe-Koenig Prisms. Waterproof 400 mbar. Operational temperature: -30 to +63 C. LotuTec and T* coatings. | Announced: March 2015. Schott HT glass. Waterproof up to 5 m. Magnesium body. AquaDura coatings. 9 optical elements woth HDC Plus coatings. |
| Score [max. 5.00] |
No score | No score | No score | ||
